  Plain Split Clamp







Plain Split Clamp

Pipe Clamps With Rubber

Construction Features :
Strengthened lock bolts for high load capacity Can be used for   both horizontal and vertical installations.
Lock bolts with combi cross recessed head.
M6 side screws with PE captive disc.
Technical Data
Welded Nut M8/M10 with option of M10/M12
Safe and Break Loads as per Chart
M6 Side Nuts can be provided on request.
Electrogalvanized as per ASTM B 633 Standards



Part No

Size Inches

Dia mm

Range mm

Dimensions ( mm)

Thickness mm

Break Load
 Kgs

Safe Load
 Kgs

A

B

C

D

DMC133018

3/8"

15

15- 19

59

20

23

30

2

600

200

DMC133022

1/2"

22

20-25

66

20

26

37

2

600

200

DMC133028

3/4"

28

26-30

72

20

29

43

2

600

200

DMC133035

1"

35

32-36

79

20

33

50

2

600

200

DMC133040

1 1/4"

42

38-43

86

20

36

57

2

600

200

DMC133048

1 1/2"

48

47-51

92

20

39

63

2

600

200

DMC133054

-

54

53-58

98

20

42

69

2

600

200

DMC133060

2"

60

60-64

104

20

45

75

2

600

200

DMC133063

-

63

63-66

108

20

47

72

2

600

200

DMC133070

-

70

68-72

114

20

50

85

2

600

200

DMC133075

2 1/2"

75

74-80

119

20

53

90

2

600

200

DMC133083

-

83

81 -86

127

20

57

98

2

600

200

DMC133090

3"

90

87-92

134

20

60

105

2

600

200

DMC133100

3 1/2"

100

99 - 105

144

20

65

115

2

600

200

DMC133110

-

110

107- 112

164

20

70

125

2

600

200

DMC133115

4"

115

113-118

159

20

73

130

2

600

200

DMC133125

-

125

125- 130

169

20

78

140

2

600

200

DMC133133

-

133

131 -137

177

20

82

148

2

600

200

DMC133140

5"

140

138- 142

184

20

85

155

2.5

900

300

DMC133150

-

150

148- 153

194

20

90

165

2.5

900

300

DMC133160

-

160

159- 166

204

25

95

175

2.5

900

300

DMC133168

6"

168

168- 172

212

25

99

183

2.5

900

300

DMC133200

8"

200

200-212

244

25

115

215

2.5

900

300

DMC133220

-

220

215-220

264

25

125

235

2.5

900

300

DMC133250

10"

250

248 -252

294

25

140

265

2.5

900

300

DMC133315

12"

315

313-318

359

25

173

330

2.5

900

300

Measurements are subject to 5% tolerance



Part No

Steel (Sch 40)

UPVC / PE

ABS

Inches

mm

DMC133018

-

-

-

16

DMC133022

1/2"

22

20

DN15 (21.4)

DMC133028

3/4"

28

25

DN20 (26.8)

DMC133035

1"

35

32 , 38

DN25 (33.6)

DMC133040

1 1/4"

42

40,43

DN32 (42.3)

DMC133048

1 1/2"

48

45

DN40 (48.3)

DMC133054

-

-

54

-

DMC133060

2"

60

60

DN50 (60.4)

DMC133063

-

-

-

-

DMC133070

-

-

70

-

DMC133075

2 1/2"

75

75

DN65 (75.4)

DMC133083

-

-

83

-

DMC133090

3"

90

90

-

DMC133100

-

-

102

DN80 (88.9)

DMC133110

-

-

110

-

DMC133115

4"

115

115

DN100 (114.3)

DMC133125

-

-

125

-

DMC133133

-

-

135

-

DMC133140

5"

140

140

DN125 (140.2)

DMC133150

-

-

152

-

DMC133160

-

-

160

-

DMC133168

6"

-

168

DN150 (168.3)

DMC133200

-

-

200

-

DMC133220

8"

219

220,225

DN200 (225.0)

DMC133250

-

-

250

DN225 (250.4)

DMC133315

-

-

-

DN300 (315.5)
